ICON 2014 F-150 2WD Suspension System - Stage 4
ICON 2014 F-150 2WD Suspension System - Stage 4
Key Features:
• Increased wheel travel and ride quality over stock with no change in towing capacity
• Vehicle specific tuned 2.5" front and rear shocks for superior shock damping and control
• External reservoir to attain cooler operating temperatures during extended offroad use
• Adjustable coilovers from 0-3" of lift height
• Uniball control arms for added strength, durability, and alignment spec range
• 6061 Aircraft grade aluminum CNC machined components
• Corrosion resistant CAD plated shock bodies with 7/8 shaft
• FK rod end bearings for extended longevity and minimal deflection
• 100% Bolt-on system - no drilling, cutting, or welding necessary for install
• Made in the USA
Overview:
The ICON Vehicle Dynamics F-150 Stage 4 suspension system is the best choice for drivers looking to maximize the on and offroad potential of their trucks and will inspire confidence behind the wheel in nearly any situation. ICON engineers’ primary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on and off-road. This system includes vehicle-specific tuned 2.5” coilover shocks featuring an external remote reservoir for exceptional cooling properties and ICON-engineered Eibach coil springs for superior vehicle “feel” through the range of travel. These coilovers are also height adjustable from 0-3” allowing the use of larger, more aggressive wheel and tire combinations. Uniball upper control arms on the F-150 not only add strength and durability, but help retain factory alignment spec range increasing caster over stock. ICON 2.5 Series Piggyback rear shocks like the 2.0 utilize a vehicle-specific valving that balances the performance of the truck from front to rear. 2.5" reservoir shocks front and rear ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during extended offroad use.The ICON Vehicle Dynamics 2014 F-150 2wd Stage 4 suspension system is an excellent choice for those drivers looking to enhance the capabilities of their pickup on the road as well as in the dirt.
Wheel & Tire Fitment Info:
OEM Wheels & Tires: No
Aftermarket Wheels: 8" - 9" Wide Wheel With 4.75" Backspace
Aftermarket Tires: 33 x 11.50 Tall Tires
(Larger Tires May Fit but Fender Trimming and Modifications will be Required)
Note - any wheel and tire combo used with out the listed backspace above will hit the shock reservoir when turning sharp and should not be used.
System Components:
91815 (QTY - 1) - 2014 Ford F150 2WD (0-3" Lift) Remote Reservoir Coilover Shocks
98500 (QTY - 1) - 2004-2014 Ford F150 2WD/4WD Uniball Upper Control Arms
97700P (QTY - 1) - 2004-2014 Ford F150 2WD/4WD (0-3" Lift) 2.5 Series Piggyback Reservoir Rear Shocks (Pair)
